Pneumatic Hand Lever Valve 5/2 3/8 NPT Detent

The Pneuforce pneumatic hand lever valve, part number N4H310-10L, is designed for manual directional control of pneumatic actuators and machine functions. It is intended for industrial pneumatic equipment and machine-control applications.

3/8 NPTPort Size
5/2Valve Function
Pneumatic Hand Lever ValveProduct Type
N4H310-10LPart Number

Technical Specifications

SpecificationDetails
Product TypePneumatic Hand Lever Valve
Part NumberN4H310-10L
Port Size3/8 NPT
Valve Function5/2
Operator ActionDetent Latching Operation
Product Detail5/2 (5 port, 2 position) 5-way operation
Product Detail 2Spool valve 5 port design
LubricationPre lubricated
Operating PressureOperating Pressure: 21 to 115 PSI
Air Quality40 micron filtered air or inert gas
HTS Code8481.20.00.10

How This Product Works

Moving the hand lever shifts the internal directional spool to change the compressed-air flow path.

Key Features

  • 3/8NPT Ports
  • Detent Latching Operation
  • 5/2 (5 port, 2 position) 5-way operation
  • Spool valve 5 port design
  • Pre lubricated
  • Operating Pressure: 21 to 115 PSI
  • 40 micron filtered air or inert gas

Typical Applications

  • Manual cylinder control
  • Machine setup functions
  • Pneumatic fixtures
  • OEM machinery
  • Maintenance and test circuits

Selection and Installation

Match the valve or component function, port size, actuation method and any electrical rating shown above to the pneumatic circuit. Use properly prepared compressed air and install the component in accordance with the machine design and applicable service requirements.

Frequently Asked Questions

What is the hand lever valve used for?

Moving the hand lever shifts the internal directional spool to change the compressed-air flow path.

What port size does this model use?

This model uses 3/8 NPT connections, as specified for part number N4H310-10L.

What valve function does this model use?

This model is specified for 5/2 operation.

Link to Pneuforce Data Sheets
Please Login or Register to review
Please Login or Register to review
Ships from Indianapolis, USA
List Price $66.21 each
10 or more $59.59 each
50 or more $52.97 each
100 or more $46.35 each
  • Stock: 51
Add to Cart
Buy Now Question about this product?
Add to Wish List Compare this Product
