Technical Specifications

Key Features

• 1/2NPT Ports
• 5/2 (5 port/2 position) operation
• Spool valve 5 port design
• Pre lubricated
• Body Ported, 4-Way, 2-Position, Spring Return
• Response Time < 20ms
• Operating Pressure: 21 to 115 PSI
• 40 micron filtered air or inert gas
• 100% ED (Continuous Duty), IP65, Class F
• Complete with coil and DIN connector

Typical Applications

• Double-acting cylinder control
• Machine automation
• Packaging machinery
• Robotics and material handling
• Industrial control panels

Selection and Installation

Match the valve or component function, port size, actuation method and any electrical rating shown above to the pneumatic circuit. Use properly prepared compressed air and install the component in accordance with the machine design and applicable service requirements.
