Pneuforce N4V430P-15-24VDC is a 5/3 solenoid directional valve. This five-port, three-position valve uses a pressure centre neutral state, which supplies pressure to both work ports in the neutral position. Select the centre state deliberately for the actuator circuit.

The primary port designation on this model is 1/2 NPT. Some multiport valves use different exhaust-port dimensions; consult the full product data before selecting fittings.

5/3 means three switching positions and 5 ports. It describes the directional flow-path arrangement, not pipe thread size.

The neutral spool position has pressure centre operation: both working ports are pressurised in neutral. Cylinder behaviour depends on load, exhaust plumbing, pressure and circuit design.

No. The 30C, 30E and 30P model functions designate five-port, three-position directional valves.

This exact model is specified for 24VDC. Match the coil rating to the control supply and check the connection type and duty rating.

A single-solenoid version typically returns by spring when de-energised; a double-solenoid two-position version can retain the last commanded spool state. Check the actual schematic and valve construction.
